Applies to: Zosi 8AP-2893W, ZR08RP, ZG2893M

AVSS for PC:
https://support.zositech.com/hc/en-us/articles/360003788292-Win-Client-AVSS

AVSS for Macbook:
https://support.zositech.com/hc/en-us/articles/360006691912-Mac-Client-AVSS

1. NVR System: ZR08RP

2. Wireless IP Camera: ZG2893A

3. System Connection:

Connect NVR to the Internet
1) Connect NVR to router using a network cable.
2) Connect monitor to NVR via HDMI or VGA port.
3) Connect the included USB mouse to the top USB port of NVR.
4) Connect NVR to 12V power supply.
5) After the system starts, pair and connect IPC and camera to the system (maximum support 8 channels).
6) The monitor will show the real-time monitoring picture of the camera.

4. Camera Installation Diagram:

❶ Following the mounting hole template to drill holes in the wall and insert the wall plugs.

❷ Align the camera Base with the mounting hole template, using the screws to fifix the base. NOTE: Place the camera wire in the notch of the camera base.

❸ Manually rotate the angle of the camera to adjust the appropriate monitoring angle.

5. How to test the network status of NVR:

1) Right click Mouse > Go to Main Menu > Setting > Network
2) Tick 'Obtain IP address automatically'
Click 'Test', if 'OK' is displayed, tick ‘DHCP’ and apply, the device will automatically assign the corresponding network segment and IP address. After clicking Test, if the page is displayed successfully, it is successfully connected to network.
NOTE: Please make sure that the DHCP of the connected router is enabled at the same time.
