Applies to: Zosi 1NC-1902F-W Camera

AVSS for PC:
https://support.zositech.com/hc/en-us/articles/360003788292-Win-Client-AVSS

AVSS for Macbook:
https://support.zositech.com/hc/en-us/articles/360006691912-Mac-Client-AVSS

Camera

Sensor: 1/2.9″ Progressive Scan CMOS
Shutter: Self-adaptive shutter
Lens: 3.6mm @ F2.0 90°
Lens Interface: M12
Minimum Illumination: 0Lux (infrared LEDs on)
Day/Night Mode: ICR infrared filter
Warm White LED: 12pcs
IR Effective Distance: 80ft in total darkness, 130ft in ambient light

Compression Standards

Video Compression Standard: H.265
Video Compression Rate: Ultra HD & SD, self-adaptive video bit rate
Audio Compression Standard: G.711A


Maximum Image Size: 1920×1080 (main stream 1080P，substream 360p)
Frame Rate: 25fps, self-adaptive network frame rate
Network Transmission: Maximum support 2 main stream and 2 substream
Data Rate: Maximum 1.0Mbps (self-adaptive)
Image Settings: Brightness, Acutance, Contrast and Saturation (set up via PC or App)
Privacy Masking: 4 blocks (set up via PC or App)

Function

Intelligent Alarm: Smart motion alerts, smart human-detect alerts
AP Hotspot: Supported
Speaker: Supported
Microphone: Supported
Mirroring: Supported (via App)
D-WDR (digital wide dynamic range): Supported
BLC (Backlight Compensation): Supported
HLC (Highlight Compensation): Supported
Protocol: ZOSI private protocol, RTSP, NTP etc
Network Status Prompt: Yes (1pc green LED on the light panel, unconnected in solid green light and flicker when connected)
Client: PC & mac
Maximum Number of Users to View Live: 20 (1 primary user, 19 sub-users)
TF Card: Supported ( FAT32 format, maximum storage 128G)

WiFi

Wireless Standards: IEEE802.11b, 802.11g, 802.11n
Frequency Range: 2.4 GHz ~2.4835 GHz
Channel Bandwidth: 20MHz
Transmission Rate: 11b:11Mbps, 11g :54Mbps, 11n :150Mbps

General

Operating Temperature & Humidity: -30℃~55℃, humidity <95% (non-condensing)
Power Supply: DC12V±10%
Power Port: DC12V/1A
Reset Button: One Reset Button
Power Consumption: 12W MAX
Ingress Protection: IP66 (waterproof & dustproof)
Dimension(mm): 166(L) × 65(W) × 65(H)mm

You can download the manual in English, French, Deutsch, Dutch, Italian, Russian and Spanish language from the attachment.

Please let us know if you have any questions.
